Compact and efficient, this Micro 3A ESC is designed for controlling small brushed DC motors in DIY projects. It supports forward, reverse, and stop functions and operates on 4.2V to 8.4V (Li-Po 1S or Ni-Mh/Ni-Cd batteries). With a 3A continuous current rating and PWM control (1000-2000µs), it’s perfect for mini RC cars, drones, robots, and other hobby electronics. No BEC included. Ideal for hobbyists and model builders.

This concise description provides the essentials for quick browsing while highlighting the product's key features.

The Micro 3A Brushed Motor Speed Controller ESC is a compact and efficient motor driver designed for small DIY RC and robotics projects. With a wide operating voltage range of 4.2V to 8.4V, this speed controller is ideal for powering brushed DC motors in a variety of mini RC cars, drones, robots, and other hobby electronics.

Key Features:

• Motor Control: Supports forward, reverse, and stop motor functionality, allowing precise speed and direction control.
• Wide Voltage Range: Compatible with Li-Po 1S (3.7V nominal) or Ni-Mh/Ni-Cd batteries (3-5 cells), making it versatile for different power setups (4.2V to 8.4V).
• Compact Size: Measuring only 20mm x 17mm, this ESC is small and lightweight, perfect for space-constrained projects.
• Current Rating: Handles continuous current up to 3A with a peak current of 4A, ideal for mini RC vehicles and other small motors.
• PWM Control: Operates with a PWM frequency range of 1000-2000 microseconds, perfect for fine motor control in your DIY projects.
• No BEC (Battery Elimination Circuit): Note that this ESC does not have a built-in BEC, so a separate power supply for your receiver or other electronics may be required.

Applications:

• Mini RC Cars
• Mini UAVs & Drones
• Mini Multi-Rotors & Robotics
• 360° Continuous Rotating Servos
• DIY Electronics Projects

Package Includes:

• 1 x Micro 3A Brushed Motor Speed Controller ESC (wires not included)

Why Choose This ESC?

• Ideal for Hobbyists: Whether you're building a custom RC car, drone, or robot, this ESC provides smooth, reliable motor control at an affordable price.
• Durable & Compact: Built for small-scale applications, this ESC is perfect for high-performance, low-power projects.
• Easy to Use: Compatible with a variety of small motors and batteries, making it a go-to choice for DIY enthusiasts and model builders.
