1. Temperature Control Range(°C): -50 to +110


2. Resolution @-9.9°C to +99.9°C: 0.1°C


3. Resolution @all temperatures: 1°C


4. Accuracy: 0.1°C


5. Refresh Rate(s): 0.5


6. Supply Voltage(V): 12


7. Measuring Inputs: NTC10K


8. Cable Length: 0.5 Meter


9. Output Type: 1 Channel Relay Output


10. Capacity: 10A

This is XH W1209 12V Digital Temperature Controller Module W/ Display and NTC Temp Sensor.

W1209 Mini thermostat Temperature controller is low-cost 12V Temperature controller with 7-segment display and 3 switch keypad for setting temperature and other parameters. The module features an NTC thermistor temperature sensing and has an accuracy of 0.1 C.

The XH W1209 digital temperature controller Module W/ Display and NTC Waterproof Temperature Sensor is an incredibly low cost yet highly functional thermostat controller. With this module, you can intelligently control power to most types of electrical devices based on the temperature sensed by the included high accuracy NTC temperature sensor.

We can display the current temperature in degrees Centigrade via its 3 digits seven-segment display and the current relay state by an onboard LED.

APPLICATION :

1. To measure and display temperature
2. To Turn any application ON/OFF based on temperature reading. (Both AC and DC)
3. Example Project:- A.Fire alarm system . B. Auto cut off Electric Water Heater

Features :

1. Power Consumption
   1. Static Current: <=35mA
   2. Current: <=65mA
2. Environmental Requirements
   1. Temperature: -10 ~ 60 C
   2. Humidity: 20-85%
