HCF4081BE IC

0 /5.0 (0 reviews)
SKU HS341

The HCF4081B IC is a monolithic integrated circuit fabricated in metal oxide semiconductor technology. It is also a QUAD 2 INPUT AND GATE that provides the system designer with direct implementation of the AND function and supplement the existing family of CMOS gates.

Read more
seller

Inhouse product

  • warranty check circle Cash on delivery available

The HCF4081B IC is a monolithic integrated circuit fabricated in metal oxide semiconductor technology. It is also a QUAD 2 INPUT AND GATE that provides the system designer with direct implementation of the AND function and supplement the existing family of CMOS gates.

Specifications

18
Product Name
HCF4081B IC
Logic Function
AND
Logic Family
HCF40
Number Of Gates
4 Gate
Number Of Input Lines
2 Input
Number Of Output Lines
1 Output
High Level Output Current
- 2.4 mA
Low Level Output Current
2.4 mA
Propagation Delay Time
250 ns
Operating Temperature Range
- 40 to +125 Degree Celsius.
Mounting Style
Through Hole
Supply Voltage Range
3V to 15V
Package / Case
PDIP-14
Function
Gate
Height
5.1 mm
Length
20 mm
Quiescent Current
20 nA
Logic Type
2-Input AND
