LM 317 IC

0 /5.0 (0 reviews)
SKU HS302

The LM317 IC is a three terminal positive voltage regulator with an adjustable features. To set the output voltage it requires only two external resistors. It has features like current limiting, thermal overload protection and safe operating area protection. It supply more than 1.5A over an output voltage range of 1.25...

Read more
seller

Inhouse product

  • warranty check circle Cash on delivery available

The LM317 IC is a three terminal positive voltage regulator with an adjustable features. To set the output voltage it requires only two external resistors. It has features like current limiting, thermal overload protection and safe operating area protection. It supply more than 1.5A over an output voltage range of 1.25V to 37V.

Specifications

16
Number Of Regulators
1
Operating Temperature
0°C ~ 125°C
Package / Case
TO-220-3 (Straight Leads)
Number Of Outputs
1
Output Voltage
1.2 V to 37 V
Line Regulation
0.04 % / V
Input Voltage Max
40 V
Reference Voltage
1.3 V
Output Noise, Rms
0.00003
Pin Current, Adjustable
50 μA (Typ.)
Regulation, Line
0.02 %/V
Voltage Output
1.2 ~ 37 V
Current Output
1.5A (Min)
Output Current
500 mA
Load Regulation
0.005
Regulation, Load
20 mV
