Max 7219 IC

0 /5.0 (0 reviews)
SKU HS294

 The MAX7219 Chip is a serial input/output common-cathode display drivers used to control a large array of LEDs. It has features like 10MHz serial interface. Individual LED segment control, digital and analog brightness control. It has low power shutdown of 150µA. It can microprocessors to 7-segment numeric LED display...

Read more
seller

Inhouse product

  • warranty check circle Cash on delivery available

 The MAX7219 Chip is a serial input/output common-cathode display drivers used to control a large array of LEDs. It has features like 10MHz serial interface. Individual LED segment control, digital and analog brightness control. It has low power shutdown of 150µA. It can microprocessors to 7-segment numeric LED displays of up to 8 digits, bar-graph displays, or 64 individual LEDs

Specifications

14
Display Type
LED
Interface
4-Wire Serial
Current - Supply
330mA
Operating Temperature
0°C ~ 70°C
Package / Case
24-DIP (0.300\", 7.62mm)
Number Of Segments
64
High Level Output Current
- 2 mA
Maximum Power Dissipation
1066 mW
Configuration
7 Segment + DP
Digits Or Characters
8 Digits
Voltage - Supply
4 V ~ 5.5 V
Mounting Type
Through Hole
Number Of Digits
8
Low Level Output Current
5 mA
