Tip 42 IC

0 /5.0 (0 reviews)
SKU HS337

The Tip 42c is a complementary power transistor that is based on island technology NPN power transistor in TO-220 plastic packaging. It is applicable for various sectors like :- audio amplifier, power linear and switching and general purpose circuits.

Read more
seller

Inhouse product

  • warranty check circle Cash on delivery available

The Tip 42c is a complementary power transistor that is based on island technology NPN power transistor in TO-220 plastic packaging. It is applicable for various sectors like :- audio amplifier, power linear and switching and general purpose circuits.

Specifications

13
Name
Tip 42c
Material of Transistor
Silicon
Transistor Type
PNP
Voltage Collector Emitter Breakdown (Max)
100V
Current Collector (Ic) (Max)
6A
Power Max
2W
DC Current Gain (hFE) (Min) @ Ic, Vce
15 @ 3A, 4V
Vce Saturation (Max) @ Ib, Ic
1.5V @ 600mA, 6A
Frequency Transition
3MHz
Current Collector Cutoff (Max)
700µA
Mounting Type
Through Hole
Lead Free Status
Lead Free
RoHS Status
RoHS Compliant
