MQ -135 Gas Sensor

0 /5.0 (0 reviews)
SKU 4( Gas sensor with module 90279090)

It is a hazardous gas detection apparatus for the family, the environment, suitable for ammonia, aromatic compounds, sulphur, benzene vapour, smoke and other gases harmful gas detection, gas-sensitive element test. Air quality sensor is for detecting a wide range of gases, including NH3, NOx, alcohol, benzene, smoke an...

Read more
seller

Inhouse product

  • warranty check circle Cash on delivery available

It is a hazardous gas detection apparatus for the family, the environment, suitable for ammonia, aromatic compounds, sulphur, benzene vapour, smoke and other gases harmful gas detection, gas-sensitive element test.

Air quality sensor is for detecting a wide range of gases, including NH3, NOx, alcohol, benzene, smoke and CO2. Ideal for use in office or factory with simple drive and monitoring circuit.

Features

  • Dual signal output (analog output, and TTL level output)
  • TTL output valid signal is low
  • Analog output with increasing concentration, the higher the concentration, the higher the voltage
  • Sulphide, benzene, smoke and other harmful gases with high sensitivity
  • Has a long life and reliable stability
  • Rapid response recovery characteristics

Specifications

13
Model
MQ 135
Working Voltage
5V
Range
 10-1000ppm
Output Voltage
0~5V
Target Gas
NH3, NOx, Alcohol, Benzene, Smoke  etc
Sensor Type
Semiconductor
Load Resistance
10K (variable via onboard potentiometer)
Heating Current
≤150mA
Heating Voltage
5.0V±0.1V
Power (Current)
150mA
DO Output
0.1V/5V
AO Output
0.1-0.3V
Size
32 X 20 X 22 mm
