RFID Reader IC

0 /5.0 (0 reviews)
SKU HS723

The RFID Reader IC is a RFID Reader MF RC522 Module. It is used in highly integrated 13.56MHz communication card chip to read and write. It has various features like: - Low voltage, Low cost, small size, and Non-contact card chip to read and write and so on. It can be suitable for various applications like:  - Smart ho...

Read more
seller

Inhouse product

  • warranty check circle Cash on delivery available

The RFID Reader IC is a RFID Reader MF RC522 Module. It is used in highly integrated 13.56MHz communication card chip to read and write. It has various features like: - Low voltage, Low cost, small size, and Non-contact card chip to read and write and so on. It can be suitable for various applications like:  - Smart home project, Voice broadcast access control system, Attendance punch card system and many more.

Specifications

13
Name
RFID Reader IC
Operating Voltage Range
3.3 V
Interface Logic Level Chip, Compatible with 3.3 V
Onboard Level Converter
Operating Current Range
13 To 26 mA
Idle Current Range
10 To 13 mA
Sleep Current
<80 uA
Peak Current
<50 mA
Operating Frequency
13.56 MHz
Supported Card Types
Mifare1 S50, Mifare1 S70 MIFARE Ultralight, Mifare Pro, MIFARE DESFire.
Data Transfer Rate
(Maximum) 10Mbit/s
Working Temperature Range
-20°C To 80°C
Storage Temperature Range
-40°C To 85°C
Humidity
5% To 95%
